Product Features

The screw conveyor was identified as the main technical equipment in Henan Province in 2018. The central groove is manufactured using advanced technology, and its service life is more than twice the service life of traditional soldering equipment. The problem of easy wear of the middle plate and the blade plate in the central groove was solved by the optimized design. The two-layer structure of the middle plate was adopted to ensure the constant strength of the groove body and increase the reliability of the equipment. The cable groove is located in several channels to insulate cables, water pipes, hydraulic pipes, etc. d. which simplifies service; At the same time, the cable groove design of double corrugated cardboard is adopted to ensure rigidity.

Scope of application

Long slaughter in coal layers of medium and large power.

Product specifications

Equipment Model SGZ1000/2x700

Transport capacity: 2500 t/h

Length : 200 m

Chain Characteristics: Φ42x146 Flat chain,

Middle groove : 1500x1000x320(mm)

Middle plate thickness: (25+30)mm

Thickness of the bottom plate: 30 mm
